Use Figure 4.11 To Sketch A Typical Seismogram

7 min read

If you’ve ever flipped through a seismology textbook and paused at figure 4.11, wondering how to use it to sketch a typical seismogram, you’re in the right place. But that little diagram is more than a pretty picture—it’s the roadmap for drawing the pulse of an earthquake’s energy as it travels through the Earth and hits your seismograph. In this post, I’ll walk you through the whole process, from setting up your axes to labeling each wave, and show you how to avoid the most common pitfalls. Ready? Let’s dive in No workaround needed..

Not the most exciting part, but easily the most useful.

What Is a Seismogram?

A seismogram is simply a graph that records ground motion over time. The horizontal axis shows time, while the vertical axis captures the amplitude of ground displacement, velocity, or acceleration—depending on the instrument. Think of it as the Earth’s diary: every tremor, whether a gentle aftershock or a giant quake, writes a unique pattern on the paper. In practice, the seismogram is the raw data that seismologists turn into insights about the Earth’s interior, fault mechanics, and hazard potential.

The Key Players

  • P‑waves: Primary, compressional waves that arrive first. They’re fast and travel through both solids and liquids.
  • S‑waves: Secondary, shear waves that arrive after the P‑waves. They can’t move through liquids, so their absence tells us about molten zones.
  • Surface waves: These ride along the Earth’s exterior and usually dominate the later part of the record. They’re slower but can cause the most damage.

Figure 4.11 lays out these waves in a clear, step‑by‑step format, making it the perfect template for a hand‑drawn seismogram.

Why It Matters / Why People Care

You might ask, “Why bother sketching a seismogram by hand?” In real‑world science, a quick sketch can reveal patterns that a spreadsheet might hide. It forces you to think about arrival times, amplitude ratios, and the relative strengths of each wave. In teaching, it’s a great visual aid—students can see the relationship between the source, propagation, and recording all in one glance. And for hobbyists who love to tinker with data, a hand‑drawn seismogram is a satisfying way to connect with the raw pulse of the planet And that's really what it comes down to..

If you skip this exercise, you miss an intuitive understanding of how wave speeds and path lengths translate into the familiar “spikes” on a seismogram. That intuition is the foundation for more advanced topics like travel‑time curves, focal‑mechanism inversion, and seismic tomography Worth knowing..

How to Use Figure 4.11 to Sketch a Typical Seismogram

Alright, let’s get our pencils ready. I’ll break the process into bite‑size chunks, each with a clear visual cue from figure 4.11 And that's really what it comes down to..

1. Set Up Your Axes

  • Time axis (horizontal): Mark evenly spaced tick marks. The scale depends on the event’s magnitude and distance. For a local quake, you might use 0.5 s per tick; for a distant event, 1 s or more.
  • Amplitude axis (vertical): Decide whether you’re plotting displacement, velocity, or acceleration. Most textbook examples use displacement. Use a consistent scale—say, 0.1 mm per tick.

Figure 4.11 shows the axes labeled as t (time) and A (amplitude). Copy that layout, and you’re halfway there It's one of those things that adds up. Simple as that..

2. Draw the Baseline

A flat line at zero amplitude represents the Earth’s quiescent state. In figure 4.On top of that, 11, this baseline is the “quiet” period before any seismic waves arrive. Keep it straight; any curvature suggests a drift or instrument error Simple, but easy to overlook..

3. Plot the P‑Wave Arrival

  • Start point: On the time axis, mark the P‑wave arrival time (tₚ). In figure 4.11, this is often the first tick after the baseline.
  • Amplitude: Draw a sharp, upward spike. The height depends on the event’s energy and your chosen amplitude scale. Keep the spike narrow—P‑waves are quick.
  • Label: Write P near the spike. In figure 4.11, the label sits just above the spike, not too close to the axis.

4. Add the S‑Wave

  • Timing: After the P‑wave, wait for the S‑wave arrival time (tₛ). The gap between tₚ and tₛ is the key to estimating the distance to the source.
  • Shape: Draw a slightly broader spike than the P‑wave. S‑waves are slower, so the rise is gentler.
  • Label: Mark it S. In figure 4.11, the S‑wave label is aligned with the spike’s peak.

5. Sketch the Surface Waves

Surface waves usually dominate the later part of the record. Figure 4.11 shows them as a series of oscillations that decay over time.

  • First surface wave: Start at tₛ + Δt, where Δt is the typical delay before surface waves appear. Draw a larger, broader wave that rises slowly.
  • Subsequent oscillations: Add a few more waves with decreasing amplitude. The pattern should look like a damped sine wave.
  • Label: Use Surf or C (for Rayleigh waves) near the first surface wave peak.

6. Add Noise and Background

Real seismograms aren’t perfect. Figure 4.11 often includes a faint background noise floor.

  • Noise: Add a wavy line around the baseline to represent ambient noise. Keep it subtle so it doesn’t drown the main waves.
  • Instrument drift: If you want to mimic a real recording, add a slight slope to the baseline.

7. Final Touches

  • Scale bars: Draw a small box indicating the time and amplitude scales.
  • Legend: If you’re using multiple colors or line styles, add a quick legend.
  • Title: Write something like “Typical Seismogram (Figure 4.11 Inspired)” to anchor the reader.

And there you have it—your hand‑drawn seismogram, faithfully following the structure of figure 4.11.

Common Mistakes / What Most People Get Wrong

Even seasoned students make these blunders when sketching a seismogram

Common Mistakes / What Most People Get Wrong

Even seasoned students make these blunders when sketching a seismogram. The most frequent pitfalls include:

  1. Misjudging the P- and S-Wave Timing Gap
    The interval between the P-wave arrival and the S-wave arrival is directly proportional to the distance from the epicenter. If you compress or stretch this gap, your distance estimate will be off. In figure 4.11, this delay is often several seconds for moderate distances—don’t rush it Turns out it matters..

  2. Drawing Waves with the Wrong Shape or Width
    P-waves are sharp, narrow spikes because they travel fastest through the Earth’s interior. S-waves are broader and slower, while surface waves are the largest in amplitude but appear last. Mixing up these characteristics creates a “Frankenstein” seismogram that confuses interpretation.

  3. Neglecting the Noise Floor
    Real instruments record background noise—tiny fluctuations even when no earthquake is active. Forgetting to include this subtle “hiss” makes your drawing look too pristine and unrealistic Easy to understand, harder to ignore..

  4. Inconsistent Scaling
    Time and amplitude axes must be scaled consistently. If your time increments are too large or your amplitude units are mismatched, the relative energy of the waves becomes distorted. Always label your scales clearly, as shown in figure 4.11.

  5. Poor Label Placement
    Labels like P, S, and Surf should be positioned to avoid overlapping with the wave peaks or the baseline. In figure 4.11, labels are placed just above the waves for clarity—don’t let them crowd the data.


Why It Matters

Creating an accurate seismogram isn’t just an academic exercise—it mirrors the real-world challenges seismologists face in interpreting data from global monitoring networks. By practicing these steps, you’re not only honing your technical skills but also building a deeper intuition for how seismic waves behave as they travel through the Earth’s layered structure. This understanding is critical for everything from calculating earthquake magnitudes to refining models of the planet’s interior.

So the next time you see a seismogram—whether in a textbook, a research paper, or a live feed from a seismic station—you’ll recognize the telltale signs of P-waves, S-waves, and surface waves. And if someone challenges you to “draw a seismogram,” you’ll know exactly how to respond It's one of those things that adds up..

Keep your baseline straight, your spikes sharp, and your labels bold. The Earth’s secrets are waiting to be decoded—one wave at a time.
